HARDWARE FEATURES

Interface 4 10/100Mbps LAN PORTS

1 10/100Mbps WAN PORT

Button WPS/RESET Button

External Power Supply 9VDC / 0.6A

Wireless Standards IEEE 802.11n, IEEE 802.11g, IEEE 802.11b

Dimensions ( W x D x H ) 7.2 x 5.0 x 1.4in.(182 x 128 x 35 mm)

Antenna 2 Antennas

WIRELESS FEATURES

Frequency 2.4-2.4835GHz

Signal Rate 11n: Up to 300Mbps(dynamic)

11g: Up to 54Mbps(dynamic)

11b: Up to 11Mbps(dynamic)

Wireless Functions Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics

Wireless Security 64/128-bit WEP, WPA / WPA2,WPA-PSK / WPA2-PSK

Transmission Power CE:

<20dBm

FCC:

<30dBm

SOFTWARE FEATURES

Quality of Service WMM, Bandwidth Control

WAN Type Dynamic IP/Static IP/PPPoE/

PPTP/L2TP

Management Features Access Control

Local Management

Remote Management

Agile Config (Optional)

DHCP Server, Client, DHCP Client List,

Address Reservation

Port Forwarding Virtual Server,Port Triggering, UPnP, DMZ

Dynamic DNS DynDns, Comexe, NO-IP

VPN Pass-Through PPTP, L2TP, IPSec (ESP Head)

Access Control Parental Control, Local Management Control, Host List, Access Schedule, Rule Management

Firewall Security DoS, SPI Firewall

IP Address Filter/MAC Address Filter/Domain Filter

IP and MAC Address Binding

Protocols Support IPv4 and IPv6

Guest Network 2.4GHz Guest Network x1

OTHERS

Certification CE, RoHS

Package Content Wireless N Router TL-WR850N

Power supply unit

Ethernet Cable

Quick Installation Guide

System Requirements Windows 2000/XP/Vista™, Windows 7, Windows 8, Windows 8.1, Windows 10 or Mac OS or Linux-based operating system

Environment Operating Temperature: 0℃~40℃ (32℉~104℉)

Storage Temperature: -40℃~70℃ (-40℉~158℉)

Operating Humidity: 10%~90% non-condensing

Storage Humidity: 5%~90% non-condensing
