Model No.

AS22TW4RXBTD00BU

Type

Inverter

Voltage, Frequency, Phase

220-240V~,50Hz

Cooling Capacity

2 Ton

22012 Btu/h

Max. input consumption

2800W

Max. current

15A

Refrigerant

R32

Indoor Unit Noise Level

46 dB (A)

Outdoor Unit Noise Level

56 dB (A)

Compressor Type ( Inverter)

Rotary

Features

Display on Front Panel

LED

Refrigerant Leakage Detect

Yes

LCD Wireless Remote Controller

Yes

Removable and washable Panel

Yes

Washable PP Filter

Yes

24 Hours Timer

Yes

3 Speed and Auto  Indoor Fan Control

Yes

Vertical Auto Swing Louver

Yes

Horizontal Auto Swing Louver（Optional）

Yes

Sleep Operation

Yes

Smart Function

Yes

Auto Restart

Yes

Dimmer

Yes

2 Ways Draining Connection (Left or Right)

Yes

Self-clean

Yes

Weight and Dimensions

Net Dimensions           WxHxD (mm)

Indoor Unit

1131×230×315

Outdoor Unit

810x585x280

Net Weight  (Kg)

Indoor Unit

14.0

Outdoor Unit

33.5

Packing Dimensions WxHxD (mm)

Indoor Unit

1220×310×400

Outdoor Unit

940x630x385

Gross Weight  (Kg)

Indoor Unit

16.5

Outdoor Unit

37.0

Warranty

Compressor

12 Year

Mainboard

4 Year

Spare part

4 Year

Other

2 Year Free Service
