Model

UH407

Physical

Color: Silver Gray Color

Casing: Aluminum, ABS

Power

Power Methods: DC / PD

DC: 5~20V 0~5A

Max Power Consumption (W):

100W if powered by a PD Adapter

15W if powered by the host client's USB Power

Idle Power Consumption (W): 0.4W

Interfaces

Upstream Connection: 1× USB-C 3.2 Gen 1 Male Connector (5 Gbps)

Video Output: 1× HDMI 2.0

Video Output Resolutions:

4K (4096×2160) 60 Hz

2K (2560×1440) 144 Hz

1080P (1920×1080) 240 Hz

Video Output Modes:

Extend, Mirror

Android phone supports mirror mode only

USB Ports:

1× USB-C 3.2 Gen 1 Port (5 Gbps)

2× USB-A 3.2 Gen 1 Ports (5 Gbps)

Memory Card Slots:

1× SD Card Slot (250 Mbps)

1× TF Card Slot (250 Mbps)

Power Input: USB-C Port

LED: Power

Requirements

Hardware Requirement:

Requires a USB-C 3.2 Gen 1 / USB4 / Thunderbolt 3/4 port on the host device

Compatible OS:

Windows 7 or later

macOS 10.12 or later

Ubuntu LTS 18.04 or later

Android 5 or higher

iPadOS

iOS

Driver Installation: Driver Free

Reliability

Operating Temperature: 0~40 °C (-32~104 °F)

Storage Temperature: -20~70 °C (-10~158 °F)

Operating Humidity: 20~85% RH non-condensing

Storage Humidity: 10~90% RH non-condensing

Mechanical

Product Weight:

64 g (2.26 oz.)

Dimension:

Main Part:

130×32×11 mm

5.12×1.26×0.43 inches

Cable:

250 mm

9.84 inches

Warranty

1-Year Brand Warranty
