• Brand: CUDY
• Model: SFP-100BASE-TX Copper SFP Transceiver
• Data Rate: 10 Mbps / 100 Mbps
• Form Factor: Hot-pluggable SFP footprint
• Connector Type: Compact RJ-45 assembly
• Compliance: RoHS compliant, lead-free
• Power Supply: Single +3.3V
• Supported Standards: IEEE 802.3 10BASE-T / 100BASE-TX
• Cable Type: Cat 5 cable for Fast Ethernet
• Operating Temperature: -40°C to +85°C

• Functions:
• RX_LOS pin for link indication
• TX_DISABLE pin to reset switch IC

• Warranty: 01-Year Brand Warranty

• Supports 10/100 Mbps Fast Ethernet – Compatible with 10BASE-T and 100BASE-TX standards
• Hot-Pluggable SFP Module – Easy installation and replacement in SFP slots
• Wide Temperature Range – Operates reliably from -40°C to +85°C
• Compact & Efficient Design – RJ-45 connector assembly, RoHS compliant, low power with +3.3V supply
• Warranty: 01-Year Brand Warranty
